Complete Electronics Hardware Design Course 2022 -EsteemPCB
Learn how to extract component information from a requirement sheet, design complex schematic blocks, and make power budget diagrams. This course covers topics such as differential pairs, interfaces like USB2.0 and I2Cs, EMI/EMC decisions, and more. You’ll also learn about PCB design, stack-up selection, components placement planning, and layout optimization. With this course, you’ll be able to design mixed signal boards using microcontrollers like STM32F407XX and STM32F103XX. Perfect for beginners and those looking to enhance their hardware designing skills.
What you’ll learn
- How to Extract Components information from Requirement Sheet
- Selection of Component for Example: Ethernet PHY, Micro-Controller, Motor Driver, Mosfets, ADC, ADC/DAC, MIC etc.
- How to Draw a Complex Schematic Block and Its Power Budget Diagrams
- What are Differential pairs, USB2.0, I2Cs, UART/USART, CAN, MII/RMII, I2S and many more interfaces
- EMI & EMC decisions for a Complex Mixed Signal Schematic Design
- How to Create Design Rules Decision for Complex Mixed Signal Board
- Layer Stack-Up Design (4L/6L/8L/12L) and Field Solver Simulation
- How to Define Board shape and Rigid-Flex PCB Board
- Components Placement planning for a Complex Board and its Execution
- How to Layout a Complex Board with more than 10,000 interconnects, and Layout Optimization
- Power Distribution Network (PDN Analysis) and How to read its Report + Resolve Issues
Show moreShow less
I have Divided this course into 4 Major Sections:
1st Section is Selection of Each Components whatever Going inside the Schematic.
2nd Section is Schematic Designing by Reading Datasheets.
3rd Stack-up 4L/6L/8L/12L, Components Placement Planning and Execution.
4th Inter Block and Intra Block Layout Planning and Execution.
Major Schematic Blocks that I have designed in this course are “Ethernet PHY 10/100 Mb/s”, “I2S DAC for Headphone and Speaker”, “MEMS MIC”, “24BIT ADC”, “36W Bi-Directional Brushed DC Motor Divers”, “UART to USB TTL Converter”, “STM32F103 Controller as Debugger and Programmer”, “STM32F407 Main Controller”, “Power Supply and Protections” and many more…. Various Subparts as you can see from the Curriculum.
You will also learn some Basic Blocks as well:
Pre-Schematic Design Blocks (Block Diagram and Power Budget)
Layer Stack-up Selection and Rules for Defining any Stack-up
Different Grounding Techniques( Signal Grounding, Earth Grounding, Chassis Grounding)
How to Create a RIGID-FLEX PCB and its Stack-up
How to do Pin-mapping using Cube-MX tool.
Power Distribution Network Analysis (PDN Analysis) of any PCB.
and many more things.
Ferrite Bead, ESD Diodes, and Magnetic Application and their selection.
How to do Placement and Layout Planning on Microsoft-Paint.
and many more….
After the completion of this course you can design any “Mixed Signal with Micro-Controller available across the world”.
Major Controller used in this course are STM32F407XX, STM32F103XX apart from that we used PHY, and Some other sensors and ADC/ DAC as well.
Who this course is for:
- People who have no experience with Hardware design and want to learn it
- People Who want to Learn Complex Mixed Signal Board Design
- People who want to learn PCB designing
- People who want to Learn How to Select Components out of millions of chip available
- People Who wan to Learn How Create a Board on Altium Designer.
- People who want to enhance their Electronic Hardware Designing Skills.
